PHI Tenor 2
PHI Tenor 2
CONTACT US FOR SPECIAL PRICES
Pre Order
Contact for delivery time
Couldn't load pickup availability
THE SPORTSTER
The first TENOR found many friends due to its extremely dynamic handling and its great performance in high-speed flight. It is the “Sportscar” in PHI’s wide range of products.
We have now carefully developed this great concept into the TENOR 2.
The TENOR 2 is a little larger than the first generation. In contrast to the first one, there are more differences between the sisters SYMPHONIA 2 and TENOR 2. The TENOR 2 has different line layout with less top lines (more diagonals), resulting in a little bit better performance.
Even having more complex internal structure, and even having more surface, the second generation of the TENOR lost weight: around 200g!
We are very happy with the safety and it’s direct and dynamic handling.
-and with the sporty characteristics of the new generation.
TENOR 2 TECHNICAL FEATURES
The TENOR 2 is a technically very complex wing for its class (low to mid B).
Due to the further reduction of the suspensions compared to its little sister SYMPHONIA 2, it has a lot more diagonal fingers in the interior.
Building on the technology of the SYMPHONIA 2, the sail tension of the TENOR 2 has been further optimized.
The handling adjustment and characteristic also uses the extended possibilities of the B class: this makes the TENOR 2 more sporty.
TENOR 2 DESIGNER’S NOTE
Even the sisters SYMPHONIA 2 and TENOR 2 are still similar, the difference in the second generation is bigger. It was worth to invest some more time and effort: finally, we found the TENOR 2 to be an extremely well-balanced wing that is a lot of fun to fly and play around with.
Hannes Papesh
TENOR 2 TECHNICAL DATA
|
TENOR 2 |
|
|||||||
|
size |
17 |
19 |
21 |
22 |
23 |
25 |
|
|
|
number of cells |
50 |
50 |
50 |
50 |
50 |
50 |
|
|
|
projected span |
m |
8,09 |
8,53 |
8,96 |
9,17 |
9,37 |
9,76 |
|
|
projected area |
m² |
17,54 |
19,53 |
21,53 |
22,54 |
23,54 |
25,54 |
|
|
projected aspect ratio |
3,73 |
3,73 |
3,73 |
3,73 |
3,73 |
3,73 |
|
|
|
flat span |
m |
10,30 |
10,87 |
11,41 |
11,68 |
11,93 |
12,43 |
|
|
flat area |
m² |
20,65 |
22,98 |
25,34 |
26.53 |
27,7 |
30,05 |
|
|
flat aspect ratio |
5,14 |
5,14 |
5,14 |
5,14 |
5,14 |
5,14 |
|
|
|
line length |
m |
6,14 |
6,48 |
6,80 |
6,96 |
7,11 |
7,41 |
|
|
maximum chord |
m |
2,49 |
2,63 |
2,76 |
2,83 |
2,89 |
3,01 |
|
|
minimum chord |
m |
0,59 |
0,62 |
0,66 |
0,67 |
0,69 |
0,71 |
|
|
weight |
kg |
3,85 |
4,2 |
4,5 |
4,65 |
4,8 |
5,2 |
|
|
standard weight range |
kg |
50-75 |
65-85 |
75-95 |
83-103 |
90-110 |
105-130 |
|
|
extended weight range |
kg |
85-95 |
95-105 |
103-113 |
110-120 |
130-140 |
|
|
|
certified weight range |
kg |
50-75 |
65-95 |
75-105 |
83-113 |
90-120 |
105-140 |
|
|
certification (EN/LTF) |
B |
B |
B |
B |
B |
B |
|
|
|
ext. weight range motor |
kg |
50-130 |
65-130 |
75-150 |
90-150 |
90-150 |
105-150 |
|
|
certification DGAC |
i.A. |
i.A. |
i.A. |
i.A. |
i.A. |
i.A. |
|
|
|
material |
MJ 30D, 20D, Skytex 40 |
|||||||
|
risers |
R01 (3+1) |
|||||||
|
riser length |
mm |
500 |
500 |
540 |
540 |
540 |
540 |
|
|
speedway |
mm |
130 |
150 |
175 |
175 |
175 |
175 |
|
TENOR 2 WEIGHT RANGES
The take off weight on the scale includes pilot + equipment + wing.
For normal thermal flying it is recommended to stay in the normal range.
For high wind conditions, strong thermals to fly XC, the extended range offers more speed, energy and possibilities.
TENOR 2 LIGHT RISERS
The TENOR 2 is delivered with the comfort riser R01.
You are free to customize and choose another riser free of charge.
When you want to go for extra light, you may choose the super light RZ1: this is reducing the weight on the tech date list by 285g!
TENOR 2 COLORS
SCOPE OF DELIVERY
Glider, Harmonica concertina packing bag, repair material
